FAQ:
Q1:What is the difference between 2.4Ghz and 5.8Ghz Wifi?
A2:The 2.4Ghz Wifi signal is better at penetrating walls, and the Wifi speed is slower than 5.8Ghzwifi. 5.8Ghz Wifi transmission speed is fast, but the signal is easily blocked by the wall
Q2: The router Wi-Fi signal is weak or the transmission distance is short?
A2: Adjusting the wifi protocol and bandwidth of the bridge will give you different network speeds and different transmission distances. You need to continuously debug to the best state for different environments and requirements.
Q3: The router support USIM or eSIM?
A3: The router is a AP router.It does not support USIM and eSIM.
Description：
The WR1208S is a high-performance enterprise-grade WiFi6 router that supports 802.11ac technology. It operates in the 2.4GHz and 5GHz wireless frequency bands, meeting the demand for simultaneous high-speed wireless internet access for up to 64 users. With gigabit network interfaces, it can achieve a maximum wireless access speed of 300Mbps in 2.4GHz mode and 867Mbps in 5.8GHz 802.11ac mode, resulting in a total wireless speed of up to 1200Mbps.
This router is characterized by its high performance, high gain, high receiver sensitivity, high bandwidth, low latency, high density, and high user capacity. It not only covers a larger area but also provides higher wireless transmission performance and stability. With its stylish design, easy installation, and support for MESH self-organizing network and relay functions, it can quickly expand wireless coverage. This makes it the perfect choice for wireless access in high-density, high-bandwidth environments such as homes, shops, restaurants, and enterprises.
Features:
1200Mbps Dual Band Wi-Fi5 Router
Supports the 802.11ac protocol, providing wireless access speeds of 300Mbps in 2.4GHz and 867Mbps in 5GHz, with a total wireless access speed of 1200Mbps.
With Gigabit Ethernet Port
The WR1208S router comes with 1x 1000Mbps WAN port and 3x 1000Mbps LAN ports,provides faster network speed for other network devices through the Ethernet port.
Support 64 Users
This router supports 64 users or devices to connect to the WiFi signal at the same time. You can choose different frequencies of WiFi signals for different devices, which can improve the utilisation of the router.
HNAT Fast Forwarding
Supports HNAT hardware fast forwarding, with bidirectional forwarding performance of up to 2Gbps on the WAN port.
Security Protection Strategy
Provides security protection through features such as WPS, WPA/WPA2, SSID hiding, guest network, MAC/IP filtering, URL control, and DDoS attack prevention, ensuring the security of user data.
Handle Various Network Scenarios
Offers a variety of network functions including router mode, bridge mode, IPv4/IPv6, IPTV, relay, MESH, DDNS, VPN client, port mapping/DMZ, traffic control, etc., to easily handle various complex network scenarios.
Quick Setup Setting
Built-in quick setup wizard, no professional knowledge required, easily connect to the router's WiFi for internet access.
Improve Device Stability
The enhanced heat sink and optimized airflow ensure that the product can operate smoothly even in hot summer days, guaranteeing real-time, long-term, stable, and efficient transmission of network data to enhance user experience.
Features MU-MIMO, OFDMA, high data rates, improved coverage, and low latency, providing better wireless network performance and user experience in high-density network environments with numerous connected devices.
Specification:
Main Chip: SF19A2890
Memory: 128MB
Flash: 16MB
2.4Ghz Wi-Fi: 802.11 b/g/n,up to 300Mbps
5Ghz Wi-Fi: 802.11 a/n/ac,up to 867Mbps
WAN Port: 1*10/100/1000Mbps
LAN Port: 3*10/100/1000Mbps
2.4G Wi-Fi Channel : 1、2、3、4、5、6、7、8、9、10、11、12、13
5G Wi-Fi Channel : 36、40、44、48、52、60、64、149、153、157、161、165
Support Wi-Fi Users/Devices Number: 64
USIM Slot: None USIM Slot
Working Temperature: 0℃ to +40℃
Storage Temperature: -20℃ to +70℃
Operating Humidity (non-condensing): 10% to 90%
Storage Humidity (non-condensing): 5% to 90%
Power: DC 12V/1A
DC power interface: Compatible with power plug with outer diameter of 5.5mm, inner diameter of 2.1mm, and length above 9.5mm
Package Listing:
1x WR1208S Dual Band Wi-Fi5 Router
1x DC 12V/1A Power Adapter
1x Ethernet Cable
1x User Manual
