Description:
Wireless KF1200 Dual Band Adapter based on IEEE 802.11ac technology delivers next generation WiFi speeds. With dual band connection, the device effectively avoids interference, ensuring top WiFi speed and reliable connections. The M-1200M is perfect for upgrading your existing laptop and desktop to a Gigabit WiFi Network.
Features:
· Ultra-fast 1200 (867+300)Mbps wireless speed with 802.11ac
· Dual Band connections for lag-free HD video streaming and gaming
· SuperSpeed USB 3.0 port—Up to 10x faster than USB 2.0
· Easy wireless security encryption at a push of the WPS button
· Equipped with a USB docking for flexible deployment
· With dual external 5dBi antennas, wifi signal is enhanced
Specifications:
|
Wireless Standards
|
IEEE 802.11ac/a/n/g/b
|
|
Interface
|
High speed USB3.0 interface
|
|
Data Rate
|
802.11ac: up to 867Mbps
802.11n: up to 300Mbps
802.11g: 54/48/36/24/18/12/9/6Mbps auto fallback
802.11b: 11/5.5/2/1Mbps auto fallback
|
|
RF Frequency
|
2.4-2.4835GHz; 5.150-5.825GHz
|
|
Radio Channel
|
1 ~ 14channels
|
|
Antenna Type
|
2 x External 5dBi Antennas
|
|
RF Output Power
|
2.4G: 17dbm±2dbm; 5G: 14dbm±2dbm
|
|
Modulation
|
802.11ac: MU-MIMO
802.11a: 5G OFDM
802.11n: MIMO-OFDM/CCK/DSSS
802.11g: CCK/DSSS/OFDM
802.11b: CCK/DSSS
|
|
Data Security
|
64/128-bit WEP Encryption, WPA, WPS
|
|
LED Indicator
|
Link/Active
|
|
Operating System
|
Windows XP/Vista/7/8/8.1/10, Linux, Mac
|
|
OperatingTemperature
|
0℃to 50℃, 20% ~ 85%RH
|
|
Storage Temperature
|
-10℃to 65℃, 10% ~ 90%RH
|
Installation Steps:
Windows system: Plug it into your computer and it will work automatically, then find the network settings where the picture appears on the screen to setting your password or use the default password.
Other computers’ system: Need to install the driver.（If the product does not contain a CD driver, please ignore）
First, insert the CD for your software installation
Second, go to Device Manager
Third, select the adapter which does not install the driver, then right-click on the Add / Update driver
Fourth, select the driver files for the corresponding system, then wait for finishing.
Or you can follow the steps that shows in the CD for how to install. Just find the file which match your computer system then to set up.
